The Secure PT1 XX1-155 is a high-precision single-phase AC current transducer designed for accurate True RMS AC current measurement and analog signal conversion in industrial power monitoring and automation systems. Featuring Accuracy Class 0.5, it provides 2 galvanically isolated analog outputs (mA or Voltage) for seamless integration with PLCs, SCADA systems, DCS, and energy management platforms. Its compact DIN rail-mounted design, configurable input/output ranges, and USB programming interface make it ideal for switchgear, motor control centers (MCC), OEM equipment, and industrial control panels.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 XX1-155 |
| Product Type | AC Current Transducer |
| System | Single Phase |
| Measurement | AC Current (True RMS) |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Current Input | 1 A / 5 A CT |
| Measuring Range | 0–150% of Nominal Current |
| Frequency | 45–55 Hz or 55–65 Hz |
| Mounting | DIN Rail (EN 50022) |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | PLC Panels, MCC, Switchgear, SCADA Systems, DCS, Industrial Automation, Energy Monitoring |
