The Secure PT1 8X1-151 is a single-phase self-powered AC voltage transducer designed for accurate AC voltage measurement and analog signal conversion in industrial power monitoring applications. Featuring Accuracy Class 0.5, it provides True RMS AC voltage measurement and 2 galvanically isolated analog outputs (mA or Voltage) for seamless integration with PLCs, SCADA systems, DCS, and energy management platforms. The self-powered design eliminates the need for an external auxiliary supply, making it ideal for switchgear, power distribution panels, and industrial automation. It offers configurable input/output ranges, DIN rail mounting, USB programming, and IEC 60688 compliance.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 8X1-151 |
| Product Type | Self-Powered AC Voltage Transducer |
| System | Single Phase |
| Measurement | AC Voltage (True RMS) |
| Accuracy Class | 0.5 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Input Voltage | 57.7–415 V AC (up to 500 V measuring range) |
| Auxiliary Supply | Self-Powered |
| Frequency | 50/60 Hz ±5% |
| Response Time | 100–220 ms |
| Mounting | DIN Rail (EN 50022) |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | Switchgear, PLC Panels, SCADA Systems, DCS, Industrial Automation, Power Monitoring, Energy Management |
