The Elite 102 Multi Function Meter (MFM) is a high-performance digital panel meter designed for accurate monitoring and analysis of electrical parameters in industrial, commercial, and utility applications. Featuring a 4-line digital display, the meter allows users to view multiple electrical parameters simultaneously, improving operational efficiency and simplifying system monitoring.
Built in a standard 96x96 mm panel mount size, the Elite 102 is ideal for installation in electrical panels, switchboards, and control systems. Its compact and rugged design ensures easy installation, long-term durability, and reliable performance in demanding environments.
The Elite 102 offers comprehensive measurement of critical electrical parameters including voltage, current, frequency, active power (kW), reactive power (kVAR), apparent power (kVA), power factor, and energy consumption (kWh, kVAh). This makes it an essential tool for energy management, load analysis, and improving power quality in electrical systems.
Designed to support three-phase 3-wire and three-phase 4-wire systems, the meter provides flexibility across a wide range of applications. It accepts current inputs through CTs (1A/5A), ensuring safe and accurate measurements in both low and high-load conditions.
The 4-line display enhances usability by enabling operators to monitor multiple parameters at once without scrolling, helping in faster troubleshooting and decision-making. Its high accuracy and stable performance contribute to reduced energy losses and optimized system efficiency.
With its robust enclosure and reliable internal components, the Elite 102 is built to withstand industrial conditions such as temperature variations, electrical disturbances, and continuous operation. It is a cost-effective and dependable solution for modern energy monitoring requirements.
Brand: Elite
Model: Elite 102
Product Type: Multi Function Meter (MFM)
Display: 4 Line Digital Display
Mounting Size: 96 x 96 mm
Connection Type:
Measured Parameters:
Voltage Input Range:
Current Input:
Frequency Range:
Accuracy Class:
Auxiliary Supply:
Dimensions (W × H):
Panel Cut-out:
Enclosure:
Weight:
