Product Description

Siemens 5SL6301-7RC MCB 1A 3-Pole C Characteristic 7.5kA

The Siemens 5SL6301-7RC is a SENTRON 5SL6 miniature circuit breaker (MCB) designed to provide dependable protection against overload and short-circuit conditions in suitable electrical installations. This MCB features a 1 A rated current, 3-pole configuration, C tripping characteristic and 7.5 kA short-circuit breaking capacity, making it suitable for appropriately designed low-current electrical distribution, control and protection applications.

The Siemens 5SL6301-7RC 1A 3-pole MCB is designed for circuits where a low-rated protective device is required with coordinated three-pole protection. Its C tripping characteristic is generally suitable for general-purpose electrical circuits where moderate starting or inrush currents may occur. This makes the device useful for selected control, auxiliary, automation and equipment protection applications.

The 3-pole configuration allows the MCB to provide coordinated protection and switching for compatible three-phase electrical systems. It can be integrated into electrical distribution boards, industrial control panels, automation cabinets, machinery panels and OEM electrical assemblies where compact multi-pole circuit protection is required.

With a 1 A rated current, the 5SL6301-7RC is particularly suited to appropriately designed low-current circuits. The correct MCB selection should always be based on the connected load, conductor capacity, system conditions and coordination with upstream and downstream protective devices.

The 7.5 kA short-circuit breaking capacity provides the specified fault-interruption capability for suitable installations. The prospective short-circuit current at the installation point should be checked before selecting the MCB to ensure that its breaking capacity is appropriate for the electrical system.

As part of the Siemens SENTRON 5SL6 series, the 5SL6301-7RC offers a compact modular solution for professional circuit protection applications. It can be considered by panel builders, OEMs, electrical contractors, system integrators, automation professionals and industrial maintenance teams.

Key Features

• Siemens 5SL6301-7RC
• SENTRON 5SL6 series miniature circuit breaker
• Rated current: 1 A
• 3-pole (3P) configuration
• C tripping characteristic
• 7.5 kA short-circuit breaking capacity
• Designed for overload protection
• Designed for short-circuit protection
• Suitable for general-purpose low-current circuits
• Suitable for circuits with moderate starting or inrush currents
• Suitable for three-phase and multi-pole electrical systems
• Suitable for industrial control panels
• Suitable for automation and control applications
• Suitable for OEM electrical equipment
• Suitable for electrical distribution boards
• Compact modular protection solution

Applications

The Siemens 5SL6301-7RC 1A 3-pole C curve MCB can be considered for:

• Industrial control circuits
• Automation control panels
• Auxiliary electrical circuits
• Machinery control systems
• Electrical distribution boards
• OEM electrical panels
• Industrial automation systems
• Manufacturing equipment
• Electrical switchboards
• Instrumentation-related circuits
• Control and signalling applications
• Building electrical systems
• Commercial electrical installations
• Industrial infrastructure
• Low-current equipment protection

Benefits

The Siemens 5SL6301-7RC provides dependable circuit protection for applications requiring a 1 A, 3-pole MCB with C characteristic and 7.5 kA breaking capacity. Its low current rating makes it suitable for appropriately designed circuits where sensitive overcurrent protection is required.

The C tripping characteristic provides a practical protection solution for general-purpose circuits where moderate starting or inrush currents may occur. It can therefore be considered for compatible control, auxiliary, automation and equipment circuits where the load profile is appropriate for a C-curve MCB.

The 7.5 kA breaking capacity provides the specified capability to interrupt suitable short-circuit fault currents. Before installation, the prospective short-circuit current should always be assessed to confirm that the selected protective device is suitable for the actual electrical system.

The 3-pole construction provides coordinated protection and switching for compatible three-phase or multi-pole circuits. This can be useful in industrial control panels, automation cabinets, machinery panels and electrical distribution assemblies where multiple poles need to be protected together.

The 1 A rated current makes the 5SL6301-7RC suitable for low-current applications where a precise protective-device rating is required. Correct coordination between the MCB rating, conductor capacity and connected equipment helps provide effective and reliable circuit protection.

The compact Siemens SENTRON 5SL6 design makes the MCB suitable for organized installation within electrical panels and distribution boards. It can be considered for industrial automation systems, OEM machinery and control applications where dependable circuit protection is required.

For customers sourcing Siemens MCBs in Faridabad, Delhi NCR, Noida, Gurgaon/Gurugram, Ghaziabad, Punjab, Mumbai, Pune, Ahmedabad, Hyderabad, Bengaluru/Bangalore, Chennai, Kolkata, Jaipur, Chandigarh, Ludhiana and other major industrial locations across India, the 5SL6301-7RC can be considered for suitable applications.

Always verify the connected load, conductor rating, system voltage, prospective short-circuit current and coordination with upstream and downstream protective devices before installation.

Why Buy Siemens 5SL6301-7RC from SB Smart?

SB Smart supplies Siemens industrial electrical, automation and circuit protection products for OEMs, panel builders, electrical contractors, system integrators and industrial maintenance teams across India.

The Siemens 5SL6301-7RC 1A 3P C characteristic 7.5 kA MCB is suitable for customers looking for Siemens circuit protection products for industrial control, automation, machinery, OEM and electrical distribution applications.

SB Smart supports sourcing requirements across Faridabad, Delhi NCR, Noida, Gurgaon/Gurugram, Mumbai, Pune, Ahmedabad, Hyderabad, Bengaluru/Bangalore, Chennai, Kolkata, Chandigarh, Ludhiana and other major industrial markets across India.

FAQs

1. What is Siemens 5SL6301-7RC?
It is a Siemens SENTRON 5SL6 miniature circuit breaker rated 1 A, 3-pole, C characteristic and 7.5 kA breaking capacity.

2. What is the rated current?
The rated current is 1 A.

3. How many poles does this MCB have?
The 5SL6301-7RC is a 3-pole (3P) miniature circuit breaker.

4. What is the tripping characteristic?
It has a C tripping characteristic, generally suitable for general-purpose circuits with moderate starting or inrush currents.

5. What is the breaking capacity?
The specified short-circuit breaking capacity is 7.5 kA.

6. Where can the Siemens 5SL6301-7RC be used?
It can be considered for suitable control panels, automation systems, auxiliary circuits, machinery, OEM equipment, distribution boards and low-current electrical applications.

7. Is this MCB suitable for industrial applications?
Yes, it can be considered for suitable industrial applications where its 1 A rating, 3-pole configuration, C characteristic and 7.5 kA breaking capacity meet the electrical system requirements.

8. What is the advantage of a 1A MCB?
A 1 A MCB is useful for appropriately designed low-current circuits where a lower protective-device rating is required. The actual selection should always be based on the connected load and complete circuit protection design.
