🔹 WATSN Remote Transfer Switch – N2R01603 (160A, 3 Pole, Remote Operated Changeover Switch)
The WATSN N2R01603 Remote Transfer Switch (RTSE) is a robust and reliable remote-operated transfer switch designed for controlled switching between two independent power sources. It enables load transfer through external control signals, making it ideal for applications where power source selection is managed remotely by PLCs, BMS systems, generator controllers, or centralized control systems.
Featuring a 160A rated current, 3-pole configuration, and 400V AC operation, the N2R01603 is built on Schneider Electric's Class PC transfer switch platform, providing safe isolation, dependable switching performance, and long service life. The switch supports three operating positions—Source I, OFF, and Source II—allowing secure transfer and maintenance operations.
Designed in accordance with IEC 60947-6-1, the N2R01603 offers high electrical durability, compact dimensions, and reliable performance for commercial, industrial, telecom, and critical power applications requiring remote source management.
• Genuine WATSN Remote Transfer Switch
• Model: N2R01603
• Rated Current: 160A
• 3-Pole configuration
• Remote-operated transfer switch (RTSE)
• Class PC transfer switch technology
• Three-position operation (Source I – OFF – Source II)
• Remote electrical control capability
• Open transition switching operation
• Compact panel-mount design
• High electrical and mechanical durability
• IEC 60947-6-1 compliant
• Suitable for utility-generator source transfer applications
| Parameter | Specification |
|---|---|
| Product Type | Remote Transfer Switch (RTSE) |
| Model Number | N2R01603 |
| Series | WATSN |
| Rated Current (Ie) | 160A |
| Number of Poles | 3 Pole |
| Rated Operational Voltage | 400V AC |
| Frequency | 50/60 Hz |
| Operation Type | Remote Electrical Operation |
| Transfer Switch Class | PC Class |
| Utilization Category | AC-33B |
| Transfer Type | Open Transition |
| Operating Positions | Source I – OFF – Source II |
| Rated Insulation Voltage (Ui) | 800V |
| Rated Impulse Withstand Voltage (Uimp) | 8kV |
| Mounting Type | Panel Mounted |
| Standard Compliance | IEC 60947-6-1 |
| Application | Remote Power Source Changeover |
