🔹 WATSN Remote Transfer Switch – N2R01602 (160A, 2 Pole, Remote Operated Changeover Switch)
The WATSN N2R01602 Remote Transfer Switch (RTS) is a high-performance remote-operated transfer switching device designed for controlled switching between two power sources. It is ideal for applications where transfer operations are managed remotely through external control systems, PLCs, building management systems, or generator control panels.
Featuring a 160A rated current, 2-pole configuration, and 230V operation, the N2R01602 provides reliable source transfer between the normal and alternate power supply. Unlike automatic transfer switches, this RTS operates through external remote commands, making it suitable for intelligent power management systems requiring centralized control.
Built on the WATSN Class PC transfer switch platform, the N2R01602 offers high switching reliability, compact construction, and compliance with IEC 60947-6-1 standards. It supports three switching positions—Source I, OFF, and Source II—ensuring safe isolation and dependable power source management.
• Genuine WATSN Remote Transfer Switch
• Model: N2R01602
• Rated Current: 160A
• 2-Pole configuration
• Remote-operated transfer switching equipment (RTSE)
• Class PC transfer switch technology
• Three-position operation (Source I – OFF – Source II)
• Remote control via external signals
• Compact panel-mount design
• High electrical and mechanical durability
• IEC 60947-6-1 compliant
• Suitable for generator and intelligent power management systems
| Parameter | Specification |
|---|---|
| Product Type | Remote Transfer Switch (RTSE) |
| Model Number | N2R01602 |
| Series | WATSN |
| Rated Current (Ie) | 160A |
| Number of Poles | 2 Pole |
| Operation Type | Remote Electrical Operation |
| Rated Operational Voltage | 220–240V AC |
| Frequency | 50/60 Hz |
| Transfer Switch Class | PC Class |
| Utilization Category | AC-33B |
| Rated Insulation Voltage (Ui) | 800V |
| Rated Impulse Withstand Voltage (Uimp) | 8kV |
| Short-Time Withstand Current (Icw) | 10kA |
| Transfer Positions | Source I – OFF – Source II |
| Mounting Type | Rail / Base Plate Mounting |
| Standard Compliance | IEC 60947-6-1 |
| Application | Remote Power Source Changeover |
