Product Description
The KTPR10.3 Electro Pneumatic Timer is a reliable time delay relay designed for industrial automation and control applications. It offers an adjustable time range of 0.5 to 60 seconds, allowing precise control over timing operations. The electro-pneumatic mechanism ensures stable and consistent performance even under voltage fluctuations and harsh industrial conditions.
This timer is equipped with 1NO + 1NC contacts, making it suitable for various control circuits. The time setting is easily adjustable through a rotary knob, providing smooth and accurate operation. Its compact panel mount design allows easy installation in control panels and machinery systems.
The KTPR10.3 is ideal for applications such as automation panels, conveyors, packaging machines, and motor control systems, where reliable and repeatable timing is essential.
Technical Specifications
🔹 General
-
Model: KTPR10.3
-
Product Type: Electro Pneumatic Timer
-
Operation Type: Time Delay Relay
-
Mounting: Panel Mount
-
Adjustment: Knob Controlled
⏱️ Timing
-
Time Range: 0.5 sec to 60 sec
-
Timing Method: Pneumatic Damping
-
Accuracy: High Repeatability
-
Reset Time: Fast Reset
🔌 Electrical
-
Supply Voltage: 24V / 110V / 230V AC
-
Contact Type: 1NO + 1NC
-
Contact Rating: 5A – 10A
-
Frequency: 50/60 Hz
⚙️ Mechanical
-
Operating Mechanism: Electro-Pneumatic
-
Operation: Smooth & Stable
-
Life Cycle: Long Mechanical Life
🌡️ Environmental
-
Operating Temperature: -10°C to +60°C
-
Humidity: Up to 95% RH
-
Vibration Resistance: Good
-
Shock Resistance: Industrial Grade
🏗️ Construction
-
Body Material: Industrial Grade Plastic / Metal
-
Control Knob: Precision Adjustable
-
Contact Material: Silver Alloy
-
Protection: Dust Resistant Design
⚡ Key Features
-
Adjustable timing up to 60 seconds
-
Stable electro-pneumatic timing system
-
Easy knob-based control
-
Reliable NO/NC contact output
-
Compact and easy panel mounting
-
Durable and long-lasting performance
-
Low maintenance design
-
Suitable for industrial automation
