The Secure PT3 X43-15F is a high-performance three-phase multifunction transducer designed for comprehensive electrical parameter measurement and analog signal conversion in industrial power monitoring and automation systems. Featuring Accuracy Class 0.5, it delivers reliable True RMS measurement of multiple electrical parameters and provides 4 galvanically isolated analog outputs for simultaneous integration with PLCs, SCADA systems, DCS, BMS, and energy management platforms. Its compact DIN rail-mounted design, configurable input/output ranges, USB programming interface, and rugged construction make it ideal for switchgear, substations, power distribution panels, OEM equipment, and industrial automation.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT3 X43-15F |
| Product Type | Three-Phase Multifunction Transducer |
| System | Three Phase |
| Measurement | Voltage, Current, Frequency, Active Power, Reactive Power, Apparent Power, Power Factor, Energy |
| Accuracy Class | 0.5 |
| Analog Outputs | 4 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Voltage Input | 3 × 100–415 V AC (L-L), 3 × 57.5–240 V AC (L-N) |
| Current Input | 1 A / 5 A CT |
| Frequency | 45–65 Hz |
| Mounting | DIN Rail (EN 50022) |
| Configuration | USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | Switchgear, Power Distribution, PLC, SCADA, DCS, BMS, Industrial Automation, Energy Management |
