The Secure PT1 X12-122 is a high-precision single-phase DC current transducer designed for accurate current measurement and signal conversion in industrial automation and power monitoring applications. Featuring Accuracy Class 0.2, the transducer provides highly accurate DC current measurement and converts the input into two galvanically isolated analog outputs for PLCs, SCADA systems, and control equipment. Its compact DIN rail-mounted design, configurable input/output ranges, and fast response time make it ideal for switchgear, process automation, OEM panels, and energy management systems.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 X12-122 |
| Product Type | DC Current Transducer |
| System | Single Phase |
| Measurement | DC Current |
| Accuracy Class | 0.2 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Current Input | DC Current (Configurable) |
| Auxiliary Supply | 80–300 V AC/DC (High) or 24–80 V DC (Low, variant dependent) |
| Mounting | DIN Rail |
| Configuration | Micro USB with ConfigView Software |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Operating Temperature | -5°C to +55°C |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | Industrial Automation, Switchgear, PLC Panels, SCADA Systems, Power Monitoring, Process Control |
