The Secure PT1 XX1-121 is a high-precision single-phase DC voltage transducer designed for accurate DC voltage measurement and signal conversion in industrial automation and power monitoring systems. With Accuracy Class 0.2, it provides highly reliable measurement performance and converts the input DC voltage into two galvanically isolated analog outputs for seamless integration with PLCs, SCADA systems, DCS, and control panels. Its compact DIN rail-mounted design, configurable output options, and fast response time make it ideal for industrial control, process automation, and energy management applications.
| Parameter | Specification |
|---|---|
| Brand | Secure |
| Model | PT1 XX1-121 |
| Product Type | DC Voltage Transducer |
| System | Single Phase |
| Measurement | DC Voltage |
| Accuracy Class | 0.2 |
| Analog Outputs | 2 Isolated Outputs |
| Output Type | Configurable (mA / Voltage) |
| Input Voltage | Configurable DC Voltage |
| Mounting | DIN Rail |
| Configuration | Micro USB with ConfigView Software |
| Response Time | ≤100–220 ms |
| Protection | IP40 (Housing), IP20 (Terminals) |
| Operating Temperature | -5°C to +55°C |
| Standards | IEC 60688, IEC 61010-1, IEC 61010-2-30, IEC 61326-1 |
| Applications | PLC Panels, SCADA Systems, DCS, Industrial Automation, Process Control, Power Monitoring |
